RG178 Cable with UHF Type Male Female Connector Cable for Mobile Car Radio Antenna Communication Antenna
- Model No.
- RG178
- Type
- Coaxial Cable
- Place of Origin
- China
- Connector
- PL259
- Color
- Black
- Length
- 5M or Customized
- Center Conductor
- Solid
- Nominal
- 1.8mm
- Shield Cover
- 100% Foil
- Attenuation db/100ft -100MHz
- 9.9
- -400MHz
- 19.7
- -900MHz
- 29.9
- -2.4GHz
- 43.8
- -5.8GHz
- 72.6
Characteristic
The combination of silver-plated copper conductors and PTFE insulation ensures signal transmission loss of less than 2.5dB/100m@3GHz, making it suitable for high-frequency in-vehicle communications.
The double-shield design (silver-plated copper braid + aluminum foil) provides ≥90dB electromagnetic interference shielding, effectively suppressing noise generated by the vehicle's electronic systems.
Core Performance
Vehicle Radio Signal Enhancement: Boosts UHF band communication range through low-loss transmission (attenuation 1.457dB/m @ 1GHz), supporting vehicle-to-vehicle relay up to 50km.
Mobile Emergency Communications: Rapidly deploys with vehicle-mounted antennas, suitable for real-time dispatch systems for specialized vehicles like police and firefighters.
Transport
We can deliver the goods to your country for you. We will load the containers for you free of charge to ensure that the goods will not be damaged during transportation.
You can either use our freight forwarding service or arrange it yourself. It all depends on you.
Although the deployment process is relatively simple, we do not currently offer installation services. However, we can provide on-site technical support for you.
- part of antenna is individual packed in PE/PVC Bag.
- Each antenna will be tuned to best performance before delivery.
- We will provide customized packaging services based on the size of your antenna products (such as length, diameter, interface type, etc.) to ensure zero damage during transportation.
- All packages have passed the 1.2m drop test
During the installation process, avoid any collisions.
It is strictly prohibited to disassemble the antenna components; otherwise, it may lead to poor antenna performance.
The installation position of the antenna should be free of any obstructions.
When used outdoors, it is necessary to equip with lightning protection facilities.
may contain electronic components. Do not discard them randomly.
